Bijur Delimon 37149115B1 Reversing Valve 115 VAC BSPP
Part Number / SKU: 37149115B1 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 20-30 business days
Overview
Bijur Delimon 37149115B1 (factory description: REV VALVE 115VAC BSPT). Reversing (changeover) valves for dual-line systems: they send pump flow to one main line while venting the other to the reservoir, then swap, so every measuring valve strokes (DL29 p.14).
Specifying, quoting, or replacing 37149115B1
Add to cart at the price shown, or use the Request a Quote form: send the part number 37149115B1, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | 37149115B1 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Valve | FR20 solenoid reversing valve |
| Max flow | 12 gpm (oil) |
| Max pressure (non-shock) | 5000 psi (3000 psi at relief port) |
| Spool | 2 position, 4 way |
| Solenoid / seals | Push type, epoxy-covered coil / Buna-N |
| Coil | 115 VAC 50-60 Hz; inrush/holding 0.49 A |
What You'll Also Need
- FR20 end-of-line systems need two pressure switches U620D1, one at the end of each supply line (DL29 p.15).
- SA-V valves need an SG-A switching device: SGA05A00 (50 bar) or SGA10A00 (100 bar) (DL29 p.15).
- A controller that accepts BDI electric reversing valves and end-of-line switches, e.g. SC400 (DL29 p.20).
Before You Order
- Full FR20 version list: BDI data sheet 35585 (DL29 p.15).
- Match the valve to the station: DC41 uses FR20 (solenoid, end-of-line); CS2000, DC36 and DC42 use DR4-5; BM-B and BS-B ship without a reversing valve (DL29 p.14-18).
- Check ratings against the measuring valves: DD/DM 3500 psi (240 bar), DDM/SDM 5075 psi (350 bar); FR20 5000 psi non-shock; SA-V 5800 psi (DL29 p.7-8, p.14-15).
- DR460A is grease-only and DR460B oil-only (both with line strainer) (DL29 p.15).
- FR20 coil voltage must match the P/N: 115 VAC (0.49 A), 230 VAC (0.24 A) or 24 VDC (1.5 A) inrush/holding (DL29 p.14).
Choosing Between Options
- FR20: 2-position 4-way solenoid valve for end-of-line systems (DC41, air-powered). DR4-5: pressure-actuated, 500-3500 psi, for non-return and return systems (DL29 p.14).
- SA-V: DC-geared-motor valve for hydraulic DuaLine systems, usable as 4/2 or 3/2, 5800 psi (400 bar) (DL29 p.15).
