Bijur Delimon V5 Lubricator
Bijur Delimon 60747-8 Lubricator V5 115 V TEFC 130 PSI Constant Volume
Part Number / SKU: 60747-8 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 30-40 business days
Overview
Bijur Delimon 60747-8 (factory description: LUB V5 115V TEFC 130 PSI CV). Bijur V5-family continuous oil lubricators and parts: a motor-driven gear pump runs with the machine, a bypass valve sets flow or pressure, and Type C control units split the oil between points.
Specifying, quoting, or replacing 60747-8
Add to cart at the price shown, or use the Request a Quote form: send the part number 60747-8, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | 60747-8 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Use | Pump & motor assembly in V5 6 L assemblies 72126 / 72126-RF (TEFC) |
What You'll Also Need
- Type C control units, one per lube point (e.g. CJB junction or CSA straight types) (DS 36734; B151 p.38)
- A system pressure gauge to set the bypass to the pre-calculated pressure (DS 36734; DS 35771)
- For V5W: the 1 gallon or 5 gallon reservoir, ordered separately (DS 35771)
- Mounting hardware for V5W: 4 x HS332 screws and 4 x HW310 washers, sold separately (DS 35771)
Before You Order
- Use Type C control units only; Type F meter units cannot be used with continuous lubricators (DS 35470; DS 36734).
- V5B generation trap: pump & motor D2944 will not fit reservoir D2559-1, and 60651/70617 will not fit old reservoir D2559 (DS 36734).
- Relief limits: 130 psi on constant-volume (CV) units; 200 psi on constant-pressure (CP) V5W and 3-phase V5 (DS 35771; DS 36811).
- Viscosity with control units: 100-10,000 SSU (V5B, V5W); 20-1500 cSt (V5 6/12/30 L assemblies) (DS 36734; DS 35771; DS 36811).
Choosing Between Options
- V5B (60443 TENV / 70618 TEFC): complete unit with 1/2 gallon reservoir, 115 VAC (DS 36734).
- V5W: pump/motor only for your 1 or 5 gallon reservoir; the only family choice for 230 VAC single-phase, 24 VDC or constant-pressure (DS 35771).
- V5 assemblies 72123-72127: complete 6, 12 or 30 L steel units with low-level switch; -RF adds a return filter; 72127 is 3-phase (DS 36811).
Product Documentation
Opens in your browser — use your browser's save option to download a copy.
Browse all Bijur Delimon products or request a quote for 60747-8 — we reply the same day.
