Bijur Delimon 73490-5233 Adapter M8 x 1 Male M10 x 1 Female
Part Number / SKU: 73490-5233 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 60-70 business days
Overview
Bijur Delimon 73490-5233 (factory description: ADAPT M8X1 MALE M10x1 FEMALE). Fittings, adapters, plugs, seals and small connection hardware used to join pumps, junctions, meter units, injectors and tube or hose in Bijur Delimon, Farval and LubeSite lubrication systems.
Specifying, quoting, or replacing 73490-5233
Add to cart at the price shown, or use the Request a Quote form: send the part number 73490-5233, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | 73490-5233 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| M8x1 compression parts (4 mm tube) | Nut 15327; bushing 15326 or 15328C; sleeve 35001 |
| M8 copper seals | 20913-6 (8.2 × 12.9 × 1 mm) or 20913-9 (8.2 × 11.4 × 1 mm) |
| M10x1 compression parts (6 mm tube) | Nut AR194; bushing 34999 (steel) or 22545 (brass) |
| M10 copper seals | 20913-1 (10.2 × 13.4 × 1 mm) or 20913-2 (10.2 × 13.9 × 1 mm) |
What You'll Also Need
- Compression joints: a nut and sleeve sized for the tube OD (B151 p.18–19); nylon tube also needs a tubing insert (p.19, e.g. 19268 for 5N25 tube).
- Straight-thread (BSPP, metric, UNF) ports: a copper seal or O-ring sized to the thread (B151 p.20–21, e.g. M8 20913-6, M10 20913-1).
Before You Order
- M8x1 (fine) and M8x1.25 (coarse) are different pitches; B151 lists separate adapters for each (AR215 M8x1, AR102 M8x1.25, p.9).
- M10x1 and M10x1.5 are different pitches; B151 lists separate adapters (B10279-1C M10x1, AR103 M10x1.5, p.9).
- Measure the thread; 1/8 NPT, 1/8 BSPT and 1/8 BSPP look alike and B151 lists separate parts and adapters for each (p.9, e.g. 36465-1 1/8BSPT × 1/8NPT).
- Bijur's small threads are easy to mix up: 5/16-24 (5/32 in or 4 mm tube), 1/4-28, M8x1 (4 mm tube) and M10x1 (6 mm tube) (B151 p.18). Check pitch with a gauge.
- Tube sizes in a name are tube OD: '1/4 Tubing' means 1/4 in OD tube, not 1/4 NPT. Measure the tube OD before choosing nut and sleeve (B151 p.18–19).
- Push-to-connect fittings are for nylon tube only, 290 psi / 20 bar max (B151 p.16–17); use compression fittings for metal tube or higher pressure.
Choosing Between Options
- Many B151 fittings exist in brass, steel and stainless with the same threads, e.g. 1/8 in tube × 1/8 NPT straight: brass 27594-1, stainless 35655-1 (B151 p.10).
- Captive-sleeve brass parts (e.g. nuts 35433, 35531, 35434) have the sleeve held in the nut; standard nuts (B1226, B146, B6531) take a loose sleeve (B151 p.18).
- Bag part numbers are quantity packs of the same part: BB1371 = 25 × B1371, BB1061 = 50 × B1061, 34497 = 10 × 15322 (B151 p.18–20).
