Product Overview
Bijur Delimon Lubricators & Pumps
Bijur Delimon 9035 55:1 Ratio Pump for 35 lb Drum
Part Number / SKU: 9035 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 20-30 business days
Overview
Bijur Delimon 9035 (factory description: 55:1 RATIO PUMP FOR 35LB DRUM). Mixed Bijur Delimon, Farval and Delimon lubricators and pumps outside a single catalog family - manual, pneumatic, electric and drum pumps and some of their parts. Specs vary by model.
Specifying, quoting, or replacing 9035
Add to cart at the price shown, or use the Request a Quote form: send the part number 9035, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | 9035 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Pump | PM3 55:1 grease pump with return tube (9000 series) |
| Container | 35 lb pail |
| Pump type | 55:1 air-operated reciprocating piston, self-priming, grease to NLGI 2 |
| Air pressure | 20-140 psi (1.5-10 bar); 90 psi (6 bar) recommended |
| Max delivery | 0.7 lb/min (21 cu in/min) |
| Max output pressure | 7,700 psi (530 bar) at 140 psi air |
| Air inlet | 1/4" NPT(F) |
| Grease outlet | 1/4" NPT(F), includes 1/2"-27 male connector |
| Return tube | Included - to bottom of drum (hose on 9035), for injector/DuaLine systems |
| Free delivery | 650 cc (40 cu in) with NLGI 2 at 70 F, 100 psi air |
| Container | 35 lb pail; drum cover and follower plate included |
| Height / weight | 24" (610 mm) / 24 lb |
Before You Order
- Seal/repair kits (DS 35993 p.5): FGK1 air motor, FGK2 packing seals, FGK3 high-pressure valve, FGK4 foot valve, FGK5 check valve + HP cylinder & piston, F740958 intake.
- HP piston and cylinder are a matched set - replace both together [DS 35993 p.3].
- Brochure DL29 lists a 3/8" NPT lube outlet; DS 35993 lists 1/4" NPT(F) with 1/2"-27 connector - check the pump in hand.
- Bung adapter for 9000 series: F366002 [DS 35993 p.5].
- These are model-specific units - order by the exact part number on the existing nameplate, and confirm voltage, reservoir size and outlet thread before ordering a replacement.
