Bijur Delimon Fittings & Junctions
Bijur Delimon A4275 Junction 3 WAY
Part Number / SKU: A4275 | Manufacturer: Bijur Delimon | Availability: In Stock at Factory - Ships in 3-5 Business Days
Overview
Bijur Delimon A4275 (factory description: JCT 3WAY). Junctions, junction bars, blocks and manifolds that split one lubricant supply line into several outlets for meter units, control units, injectors or tubing.
Specifying, quoting, or replacing A4275
Add to cart at the price shown, or use the Request a Quote form: send the part number A4275, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | A4275 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
What You'll Also Need
- Connector nipples to join junction bars end to end: 20124 (5/16-24), 15822 (M8x1), 25632 (M10x1) (B151 p.8)
- 5/16-24 closure plug B3784 for unused ports, and nut B1095 or bushing B1371 + sleeve B1061/B8272 for 5/32 in tube (B151 p.18-19)
- Meter units (FJB/FJC/FJD, AJB) or control units (CJB/CJC/CJD) sized for each outlet (DS 35470; B151 p.34-41)
Before You Order
- Match the thread family: 5/16-24 (5/32 in tube), M8x1 (4 mm), M10x1 (6 mm), 1/8 NPTF or 1/8 BSPT (B151 p.49-55).
- 5/16-24 bars come in two bodies: die-cast for FJB/FJC/CJB/CJC, and aluminum bar stock for the thinner FJD/CJD units (B151 p.52-55; DS 35470).
- Push-to-connect bars (60330-x) take nylon tube only, 290 psi (20 bar) max (B151 p.16-17, 55).
Choosing Between Options
- Junction headers B1503 etc. are for FT/CT tee units; B7682-B7694 are plain 1/8 NPTF aluminum junction blocks (B151 p.48-49).
- Double-sided bars fit more outlets in less length: 6-way B3109 is 48 mm long vs 80 mm for single-sided B3264 (B151 p.52, 54).
