Bijur Delimon AirMax Lubricator
Bijur Delimon AMA2T3BBB1AH Lubricator Airmax 115 V 3 x .06 Timer Pressure Switch
Part Number / SKU: AMA2T3BBB1AH | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 25-35 business days
Overview
Bijur Delimon AMA2T3BBB1AH (factory description: LUB AIRMAX 115V 3X.06 TIMER PS). AirMax is an air-oil lubricator: an air-actuated piston pump with an integrated air-oil injection block that sends oil doses in a continuous air stream to the nozzle - for chain conveyors and spindles.
Specifying, quoting, or replacing AMA2T3BBB1AH
Add to cart at the price shown, or use the Request a Quote form: send the part number AMA2T3BBB1AH, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | AMA2T3BBB1AH |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Pump | Air-actuated, spring-return piston pump with integrated air-oil injection block |
| Supplied with | Pressure gauge and oil inlet filter |
What You'll Also Need
- FRL on the pump air supply (dry air); typical machine air 60-80 psi, 10 SCFM (FL 36983).
- Separate filter-regulator for the continuous air to the air-oil block, typical setting 10-30 psi (FL 36983).
- 5/16" O.D. tubing to the nozzle; nozzle 27107-1 (5/16-24 F, 2.5 mm orifice) in a bracket tapped 1/8" NPTF (FL 36983; Catalog B151 p.71).
Before You Order
- With PDI injectors the pump needs at least 260 psi (18 bar) oil pressure; output pressure is set by inlet air pressure (FL 36983).
- Pump is cycled by a 3/2-way solenoid; typical 5 s on and 30-300 s off (FL 36983).
- The number of injectors and dose per port are fixed by the part number; the flyer does not publish the code, so confirm outlets and doses with BDI (FL 36983).
Choosing Between Options
- Stand-alone with the on-board timer, or tie into existing machine controls; options include low oil switch, oil pressure switch and wash-down (CIP) enclosures (FL 36983).
