Bijur Delimon B10101 Branch Tee

Part Number / SKU: B10101  |  Manufacturer: Bijur Delimon  |  Availability: In Stock at Factory - Ships in 3-5 Business Days

Specifying, quoting, or replacing B10101

Add to cart at the price shown, or use the Request a Quote form: send the part number B10101, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.

Key Specifications

What You'll Also Need

• Compression joints: a nut and sleeve sized for the tube OD (B151 p.18–19); nylon tube also needs a tubing insert (p.19, e.g. 19268 for 5N25 tube).
• Straight-thread (BSPP, metric, UNF) ports: a copper seal or O-ring sized to the thread (B151 p.20–21, e.g. M8 20913-6, M10 20913-1).

Before You Order

• Measure the thread; 1/8 NPT, 1/8 BSPT and 1/8 BSPP look alike and B151 lists separate parts and adapters for each (p.9, e.g. 36465-1 1/8BSPT × 1/8NPT).
• Bijur's small threads are easy to mix up: 5/16-24 (5/32 in or 4 mm tube), 1/4-28, M8x1 (4 mm tube) and M10x1 (6 mm tube) (B151 p.18). Check pitch with a gauge.
• Tube sizes in a name are tube OD: '1/4 Tubing' means 1/4 in OD tube, not 1/4 NPT. Measure the tube OD before choosing nut and sleeve (B151 p.18–19).
• Push-to-connect fittings are for nylon tube only, 290 psi / 20 bar max (B151 p.16–17); use compression fittings for metal tube or higher pressure.
• If the part is not in the B151 tables, match it by the P/N stamped on the old part or on the unit's parts list, not by appearance.

Choosing Between Options

• Many B151 fittings exist in brass, steel and stainless with the same threads, e.g. 1/8 in tube × 1/8 NPT straight: brass 27594-1, stainless 35655-1 (B151 p.10).
• Captive-sleeve brass parts (e.g. nuts 35433, 35531, 35434) have the sleeve held in the nut; standard nuts (B1226, B146, B6531) take a loose sleeve (B151 p.18).
• Bag part numbers are quantity packs of the same part: BB1371 = 25 × B1371, BB1061 = 50 × B1061, 34497 = 10 × 15322 (B151 p.18–20).
