Bijur Delimon B3764 Junction 4 WAY Single Aluminum
Part Number / SKU: B3764 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 95-105 business days
Overview
Bijur Delimon B3764 (factory description: JCT 4WAY SGLE ALUM). Junctions, junction bars, blocks and manifolds that split one lubricant supply line into several outlets for meter units, control units, injectors or tubing.
Specifying, quoting, or replacing B3764
Add to cart at the price shown, or use the Request a Quote form: send the part number B3764, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | B3764 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Type | 4-way junction bar, aluminum, single-sided, 2 mounting holes |
| Outlets | 2 x 5/16-24 |
| Through-ports (inlet) | 2 x 5/16-24, one each end |
| Length / outlet span | 1.562" (39.7 mm) overall; 1.125" (28.6 mm) outlet span |
| Takes | FJD / CJD meter and control units |
What You'll Also Need
- Connector nipples to join junction bars end to end: 20124 (5/16-24), 15822 (M8x1), 25632 (M10x1) (B151 p.8)
- 5/16-24 closure plug B3784 for unused ports, and nut B1095 or bushing B1371 + sleeve B1061/B8272 for 5/32 in tube (B151 p.18-19)
- Meter units (FJB/FJC/FJD, AJB) or control units (CJB/CJC/CJD) sized for each outlet (DS 35470; B151 p.34-41)
Before You Order
- Match the thread family: 5/16-24 (5/32 in tube), M8x1 (4 mm), M10x1 (6 mm), 1/8 NPTF or 1/8 BSPT (B151 p.49-55).
- 5/16-24 bars come in two bodies: die-cast for FJB/FJC/CJB/CJC, and aluminum bar stock for the thinner FJD/CJD units (B151 p.52-55; DS 35470).
- Push-to-connect bars (60330-x) take nylon tube only, 290 psi (20 bar) max (B151 p.16-17, 55).
Choosing Between Options
- Junction headers B1503 etc. are for FT/CT tee units; B7682-B7694 are plain 1/8 NPTF aluminum junction blocks (B151 p.48-49).
- Double-sided bars fit more outlets in less length: 6-way B3109 is 48 mm long vs 80 mm for single-sided B3264 (B151 p.52, 54).
