Bijur Delimon Dualine Central Station
Bijur Delimon CS2207 Central Station - 6 gal Oil
Part Number / SKU: CS2207 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 20-30 business days
Overview
Bijur Delimon CS2207 (factory description: CENTRAL STATION - 6 GAL OIL). Central pumping stations for Farval DuaLine systems - motor, pump, reservoir and reversing valve as one unit (DL29 p.16) - plus air control panels, valve panels and single-line stations.
Specifying, quoting, or replacing CS2207
Add to cart at the price shown, or use the Request a Quote form: send the part number CS2207, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | CS2207 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Model | CS2000 DuaLine central station |
| Voltage | 230/460 VAC 50/60 Hz, 3-phase |
| Reservoir | 6 gal steel |
| Level switches | Low + high |
| Motor | Included |
| Pump output | 6.0 in³/min (double piston, pump DJ-2000) |
| Max working / relief pressure | 3500 psi / 3000 psi |
| Reversing valve | DR4-5, factory 1500 psi, range 500-3500 psi |
| Motor (when fitted) | 1/3 hp, TEFC, 48 frame; gear ratio 10:1 |
| Lubricant / system | Oil or grease / non-return (field-convertible to loop) |
What You'll Also Need
- A controller such as the SC400 (85-265 VAC), which operates and monitors DuaLine systems with electric or hydraulic reversing valves (DL29 p.20).
- DC41 stations: two U620D1 end-of-line pressure switches for the FR20 reversing valve (DL29 p.15-16).
- CS2000 without motor (CS24xx): motor mounting kit LC10705 (48 frame) or LC10706 (56 frame) (DL29 p.17).
Before You Order
- Standard: level-warning switch, visual level indication, adjustable relief valve; NEMA 4 and control-mounting kits available (DL29 p.16).
- DL29 lists standard stations at 230/460 VAC 50/60 Hz 3-phase; other voltages are special - confirm with BDI (DL29 p.17).
- Keep relief and reversing pressure below the measuring-valve rating: DD/DM 3500 psi (240 bar) (DL29 p.7, p.17).
Choosing Between Options
- CS2000: 6.0 in³/min, 3500 psi, DR4-5 reversing - small machine tools up to steel-mill machinery. DC41/DC42: 33.6 in³/min, 3000 psi - bar mills, blast furnaces (DL29 p.16-17).
- DC41 reverses by end-of-line pressure switches and FR20 solenoid; DC42 by a DR4-5 valve that trips a micro switch to stop the motor (DL29 p.16).
