Bijur Delimon Valve
Bijur Delimon DR45 Reversing Valve
Part Number / SKU: DR45 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 15-25 business days
Overview
Bijur Delimon DR45 (factory description: REVERSING VALVE). Reversing (changeover) valves for dual-line systems: they send pump flow to one main line while venting the other to the reservoir, then swap, so every measuring valve strokes (DL29 p.14).
Specifying, quoting, or replacing DR45
Add to cart at the price shown, or use the Request a Quote form: send the part number DR45, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | DR45 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Valve | DR4-5 hydraulic reversing valve, basic valve |
| Valve | DR4-5 pressure-actuated reversing valve |
| Pressure range | 500-3500 psi, adjustable |
| Lubricant | SAE 10 oil to NLGI 2 grease |
| Materials / seals | Zinc housing, yellow chromate; low-carbon steel piston / Buna-N |
What You'll Also Need
- FR20 end-of-line systems need two pressure switches U620D1, one at the end of each supply line (DL29 p.15).
- SA-V valves need an SG-A switching device: SGA05A00 (50 bar) or SGA10A00 (100 bar) (DL29 p.15).
- A controller that accepts BDI electric reversing valves and end-of-line switches, e.g. SC400 (DL29 p.20).
Before You Order
- Used with CS2000, DC36 and DC42 stations and with air barrel pumps for spray and medium/large DuaLine systems (DL29 p.14).
- Match the valve to the station: DC41 uses FR20 (solenoid, end-of-line); CS2000, DC36 and DC42 use DR4-5; BM-B and BS-B ship without a reversing valve (DL29 p.14-18).
- Check ratings against the measuring valves: DD/DM 3500 psi (240 bar), DDM/SDM 5075 psi (350 bar); FR20 5000 psi non-shock; SA-V 5800 psi (DL29 p.7-8, p.14-15).
- DR460A is grease-only and DR460B oil-only (both with line strainer) (DL29 p.15).
- FR20 coil voltage must match the P/N: 115 VAC (0.49 A), 230 VAC (0.24 A) or 24 VDC (1.5 A) inrush/holding (DL29 p.14).
Choosing Between Options
- FR20: 2-position 4-way solenoid valve for end-of-line systems (DC41, air-powered). DR4-5: pressure-actuated, 500-3500 psi, for non-return and return systems (DL29 p.14).
- SA-V: DC-geared-motor valve for hydraulic DuaLine systems, usable as 4/2 or 3/2, 5800 psi (400 bar) (DL29 p.15).
