Bijur Delimon EBP46A1 Pump Assembly, 460 VAC, 400 lb, Progressive
Part Number / SKU: EBP46A1 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 20-30 business days
Overview
Bijur Delimon EBP46A1 (factory description: PUMP ASSY,460VAC,400LB,PROG). Electric barrel pumps (EBP) fit 120 lb and 400 lb grease drums and replace air- or hydraulic-operated barrel pumps on mobile or stationary equipment, wiring straight into machine power.
Specifying, quoting, or replacing EBP46A1
Add to cart at the price shown, or use the Request a Quote form: send the part number EBP46A1, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | EBP46A1 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
What You'll Also Need
- Lube containers (drums) are sold separately; bung adapter F360002 is included with each pump (Brochure 33136 p.20).
Before You Order
- 460 VAC is not one of the voltage codes (24/11/22) in Brochure 33136 p.20 - confirm the build with BDI.
- Fuse per voltage: 24 VDC draws 15 A (16 A spike, 40 A fuse max); 115 VAC 4 A (7 A fuse max); 220 VAC 2 A (4 A fuse max) at 3500 psi with NLGI 2 (Brochure 33136 p.20).
- Rated flow is for 60 Hz motors; 60 Hz motors run on 50 Hz at reduced flow (Brochure 33136 p.20).
Choosing Between Options
- Valve option 1 = progressive with relief valve; options 2/3/4 = injector systems with a 24 VDC, 110 VAC or 220 VAC vent valve (Brochure 33136 p.20).
- For DuaLine systems the EBP is suitable when paired with a hydraulic or electric reversing valve (Brochure 33136 p.20).
