Bijur Delimon Divider Valve
Bijur Delimon ZPA05A01ILLLL00 Manifold ZPA Divider Valve
Part Number / SKU: ZPA05A01ILLLL00 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 40-50 business days
Overview
Bijur Delimon ZPA05A01ILLLL00 (factory description: MANIFOLD ZPA DIVIDER). Service part (seal, plug, segment, switch or kit) for a Delimon ZP-A/ZP-B progressive distributor; it does not meter lubricant on its own.
Specifying, quoting, or replacing ZPA05A01ILLLL00
Add to cart at the price shown, or use the Request a Quote form: send the part number ZPA05A01ILLLL00, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | ZPA05A01ILLLL00 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Order code | ZPA05A01ILLLL00 |
| Segments | 5 segments, up to 10 outlets |
| Approx. weight | 1.72 kg |
| Monitoring (code 01) | Non-return valves + motion indicator (visual) |
| Accessory (code 00) | None |
| Max working pressure | 160 bar |
| Metered volume per piston stroke | 0.1, 0.2 or 0.3 cm³ (by segment) |
| Outlets | Up to 24 (2 per segment, 3-12 segments) |
| Flow range (oil and grease) | 0.5-1000 cm³/min |
| Response pressure / non-return valve opening | 10 bar / 2 bar |
| Lubricants (mineral-oil based) | Grease to NLGI 3 (DIN 51818); oil ISO VG 68-1500 at 20 °C ambient |
| Temperature | -20 to +80 °C with proximity indicator; -20 to +110 °C without |
| Connections | Inlet G 1/8 (standard Ø10 tube); outlets G 1/8 (Ø6 tube) |
Before You Order
- Max differential pressure between two outlets is 50 bar; with the built-in non-return valves, up to the admissible system pressure (P_2005_1_GB_ZPA p.3).
- Read the full distributor order code on the block (e.g. ZPA03A01III00) before ordering seals, plugs or segments; the code gives segment count and monitoring type (P_2005_1_GB_ZPA p.2).
- A standard ZP-A has at least 3 segments: one A (initial), M (middle) and E (final) segment - order the segment type you are replacing (P_2005_1_GB_ZPA p.1).
