Bijur Delimon Divider Valve
Bijur Delimon ZPB05A01IIIIC00 Divider Valve
Part Number / SKU: ZPB05A01IIIIC00 | Manufacturer: Bijur Delimon | Availability: Made to Order - Lead Time: 40-50 business days
Overview
Bijur Delimon ZPB05A01IIIIC00 (factory description: DIVIDER ZPB05A01IIIIC00). Delimon ZP-A progressive distributors (plus ZP-B and ZAG variants) and their service parts. A ZP-A block splits one supply line's oil or grease into metered doses delivered in turn to up to 24 outlets.
Specifying, quoting, or replacing ZPB05A01IIIIC00
Add to cart at the price shown, or use the Request a Quote form: send the part number ZPB05A01IIIIC00, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | ZPB05A01IIIIC00 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
What You'll Also Need
- Screw joint kit sized to the outlet count: accessory code 04 (1-4 outlets) through 09 (21-24 outlets) in the ZP-A order code (P_2005_1_GB_ZPA p.2).
- Overpressure indicator to show a blockage: 70 bar (accessory code 02) or 100 bar (code 03) (P_2005_1_GB_ZPA p.2).
- Controller: SMAC-MAX 42012-5 (110 VAC) or 42012-4 (220 VAC) runs progressive systems in cycle-control mode d3 off a divider cycle switch (DS 36830 p.3).
Before You Order
- ZP-B and ZAG order codes are not covered by the ZP-A data sheet P_2005; confirm pressure and dose data with BDI using the full order code on the nameplate.
- A piston's dose leaves through the adjacent segment toward the inlet, and the A-segment dose leaves at the E-segment - check this before cross-porting outlets (P_2005_1_GB_ZPA p.3).
- Monitoring code 01 = motion indicator (visual), 02 = monitoring switch (electrical). Electrical monitoring is an add-on to the motion-indicator version (P_2005_1_GB_ZPA p.1-2).
- Outlet letters in the code (e.g. I, A, Q) are set by BDI's segment price list, not the data sheet - quote the full order code from the nameplate to get the same doses (P_2005_1_GB_ZPA p.2).
- With a proximity indicator the ZP-A is limited to -20 to +80 °C; without, -20 to +110 °C (P_2005_1_GB_ZPA p.3).
Choosing Between Options
- ZP-A (progressive, one supply line, 160 bar max) vs ZV-B (dual-line, 400 bar max, doses each point independently of back pressure) (P_2005_1_GB_ZPA p.3; P_2018_1_GB_ZVB p.1-4).
- Metered volume per piston stroke is 0.1, 0.2 or 0.3 cm³ by segment choice; larger doses per point by cross-porting outlets (P_2005_1_GB_ZPA p.3).
Product Documentation
Opens in your browser — use your browser's save option to download a copy.
Browse all Bijur Delimon products or request a quote for ZPB05A01IIIIC00 — we reply the same day.
