Farval F1402 Hose Reel with Swivel Low/Med Pressure
Part Number / SKU: F1402 | Manufacturer: Farval | Availability: Made to Order - Lead Time: 30-40 business days
Overview
Farval F1402 (factory description: HOSE REEL W/SWVL LOW/MED PRESS). Mounting stand or frame for Farval hose reels.
Specifying, quoting, or replacing F1402
Add to cart at the price shown, or use the Request a Quote form: send the part number F1402, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | F1402 |
| Brand | Farval |
| Selling unit | Each (1 piece) |
| Reel series | 1400 standard |
| Service | Medium pressure oil/fluids |
| Hose | Reel only with swivel, no hose |
| Pressure rating | 3000 psi swivel |
| Construction | Heavy-gauge welded plate steel, hardened shaft, permanently lubricated bearings |
| Guide arms | Adjustable to 3 positions: wall, ceiling, floor, pit or truck mounting |
| Spring | Enclosed floating spring canister, replaceable |
| Latch | Non-sparking, with audible lock |
| Series | Standard-capacity 1400 series; holds up to 40 ft of 1/2" hose (1/4", 3/8", 1/2" ID) |
| Swivel inlet | 1/2" NPT(F) medium pressure; 1/4" NPT(F) high pressure |
| Dimensions | approx. 20-3/4" x 18-7/8" x 8-5/8" (525 x 480 x 220 mm) |
| Rating | Reel only with swivel, 3000 psi; no hose (medium pressure oil/fluids) |
Before You Order
- Reels include the inlet swivel; models with hose include a hose stop [Brochure 33136 p.23].
- Matching 1-wire braid hoses: F851 (30 ft) or F853 (40 ft), 1/2" ID, 2000 psi [Brochure 33136 p.23].
- Match F1402 to the part number on the old part, the unit nameplate or the unit parts list before ordering.
