Bijur Delimon Valve
Bijur Delimon 201594 Valve Solenoid 120 VAC 1/2 NPT NEMA4X
Part Number / SKU: 201594 | Manufacturer: Bijur Delimon | Availability: In Stock at Factory - Ships in 3-5 Business Days
Overview
Bijur Delimon 201594 (factory description: VALVE SOL 120VAC 1/2NPT NEMA4X). Solenoid valves that switch air or lubricant flow on an electrical signal: air valves for pneumatic lubricators and mist/air-oil units, and grease/oil zone shut-off valves.
Specifying, quoting, or replacing 201594
Add to cart at the price shown, or use the Request a Quote form: send the part number 201594, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.
Key Specifications
| Manufacturer part number | 201594 |
| Brand | Bijur Delimon |
| Selling unit | Each (1 piece) |
| Catalog listing | Solenoid valves — pneumatic |
| Voltage | 120VAC |
| Hz | 50/60 |
| Elec. conn. | 1/2NPTF |
| Holding | 0.133 A |
| Inrush | 0.333 A |
| Inlet | 1/2NPTF |
| Outlet | 1/2NPTF |
| Type | 2/2 |
| Flow max | 4.0Cv |
| NEMA | 4X |
| Temp | 32–125°F |
| Max pressure | 150 psi (10.3 bar), air |
| Function | Normally closed (N.C.) |
What You'll Also Need
- Mating electrical connector: DIN 43650 form A MCC2510A, form B MCC2509A, or 3-pin automotive cable MCC2505A (6 ft) / MCC2505B (12 ft) (B151 p.76).
Before You Order
- Match coil voltage and electrical connection to the controller output: the 20311 series alone comes with 120 VAC, 240 VAC and 24 VDC coils and 1/2NPS conduit or DIN 43650A (B151 p.43).
- Check the medium: B151 p.43 valves are air valves, 150 psi max (VAL10662B 250 psi); grease/oil zone valves are MCZ2503/2504 (3000 psi) or 39909/37214/37196 (5000 psi) (p.44–45).
- Check function: in B151 the 3/2 valves have an exhaust port and the 2/2 valves do not; most listed valves are normally closed (N.C.) (p.43–45).
Choosing Between Options
- Explosion-proof air valves listed: VAL10107B (NEMA 3/4/4X/7/9) and VAL13038A (NEMA 4X/7/9), both 1/2NPTF 2/2 (B151 p.43).
- High-temperature coils (32–356°F) with junction box: VAL13717A (3/2, 1/4NPTF) and VAL13718A (2/2, 1/2NPTF) (B151 p.43).
