Bijur Delimon C3245-1 Valve Solenoid 120 VAC

Bijur Delimon Valve

Bijur Delimon C3245-1 Valve Solenoid 120 VAC

Part Number / SKU: C3245-1  |  Manufacturer: Bijur Delimon  |  Availability: In Stock at Factory - Ships in 3-5 Business Days

Specifying, quoting, or replacing C3245-1

Add to cart at the price shown, or use the Request a Quote form: send the part number C3245-1, the quantity, and a photo of the nameplate or the old part, and we reply the same day. L. DeWitt McCarter is an authorized Bijur Delimon, Farval and LubeSite distributor in San Antonio, TX — (210) 494-1997.

Key Specifications

What You'll Also Need

• Mating electrical connector: DIN 43650 form A MCC2510A, form B MCC2509A, or 3-pin automotive cable MCC2505A (6 ft) / MCC2505B (12 ft) (B151 p.76).

Before You Order

• Listed as the FluidFlex UB/UC solenoid valve: B9960 24 VDC, C3245-1 120 VAC, C3245-2 240 VAC (DS 24421).
• Match coil voltage and electrical connection to the controller output: the 20311 series alone comes with 120 VAC, 240 VAC and 24 VDC coils and 1/2NPS conduit or DIN 43650A (B151 p.43).
• Check the medium: B151 p.43 valves are air valves, 150 psi max (VAL10662B 250 psi); grease/oil zone valves are MCZ2503/2504 (3000 psi) or 39909/37214/37196 (5000 psi) (p.44–45).
• Check function: in B151 the 3/2 valves have an exhaust port and the 2/2 valves do not; most listed valves are normally closed (N.C.) (p.43–45).

Choosing Between Options

• Explosion-proof air valves listed: VAL10107B (NEMA 3/4/4X/7/9) and VAL13038A (NEMA 4X/7/9), both 1/2NPTF 2/2 (B151 p.43).
• High-temperature coils (32–356°F) with junction box: VAL13717A (3/2, 1/4NPTF) and VAL13718A (2/2, 1/2NPTF) (B151 p.43).

Product Documentation

Opens in your browser — use your browser's save option to download a copy.
